• Super small-size & light weight
• Harmonic attenuator (Complies with IEC61000-3-2): except PBA1500T
• Universal input (AC85 - 264V): PBA1500T AC170-264V 3Φ
• Efficiency increased with synchronous rectification technology (PBA50F - 150F)
• Variety of option (PBA10F - 150F, PBW15F - 50F)
• Parallel operation and Parallel redundancy operation (PBA300F - 1500F, PBA1500T)
• Fan alarm, Remote ON/OFF and other functions (PBA300F - 1500F, PBA1500T)
PB(1) A(2) 10(3) F(4) - □(5) - □(6)
(1) Series name
(2) Single output
(3) Output wattage
(4) Universal input
(5) Output voltage
(6) Optional
|
型號 |
輸入電壓 |
輸出瓦數 |
輸出電壓／電流 |
|
PBA10F-5 |
1Φ AC85～264V |
10W |
5V 2A |
|
PBA10F-12 |
1Φ AC85～264V |
10.8W |
12V 0.9A |
|
PBA10F-24 |
1Φ AC85～264V |
12W |
24V 0.5A |
|
PBA15F-3R3 |
1Φ AC85～264V |
9.9W |
3.3V 3A |
|
PBA15F-5 |
1Φ AC85～264V |
15W |
5V 3A |
|
PBA15F-9 |
1Φ AC85～264V |
15.3W |
9V 1.7A |
|
PBA15F-12 |
1Φ AC85～264V |
15.6W |
12V 1.3A |
|
PBA15F-15 |
1Φ AC85～264V |
15W |
15V 1A |
|
PBA15F-24 |
1Φ AC85～264V |
16.8W |
24V 0.7A |
|
PBA15F-48 |
1Φ AC85～264V |
16.8W |
48V 0.35A |
|
PBA30F-3R3 |
1Φ AC85～264V |
19.8W |
3.3V 6A |
|
PBA30F-5 |
1Φ AC85～264V |
30W |
5V 6A |
|
PBA30F-9 |
1Φ AC85～264V |
30.6W |
9V 3.4A |
|
PBA30F-12 |
1Φ AC85～264V |
30W |
12V 2.5A |
|
PBA30F-15 |
1Φ AC85～264V |
30W |
15V 2A |
|
PBA30F-24 |
1Φ AC85～264V |
31.2W |
24V 1.3A |
|
PBA30F-48 |
1Φ AC85～264V |
31.2W |
48V 0.65A |
|
PBA50F-3R3 |
1Φ AC85～264V |
33W |
3.3V 10A |
|
PBA50F-5 |
1Φ AC85～264V |
50W |
5V 10A |
|
PBA50F-9 |
1Φ AC85～264V |
50.4W |
9V 5.6A |
|
PBA50F-12 |
1Φ AC85～264V |
51.6W |
12V 4.3A |
|
PBA50F-15 |
1Φ AC85～264V |
52.5W |
15V 3.5A |
|
PBA50F-24 |
1Φ AC85～264V |
52.8W |
24V 2.2A |
|
PBA50F-36 |
1Φ AC85～264V |
50.4W |
36V 1.4A |
|
PBA50F-48 |
1Φ AC85～264V |
52.8W |
48V 1.1A |
|
PBA75F-3R3 |
1Φ AC85～264V |
49.5W |
3.3V 15A |
|
PBA75F-5 |
1Φ AC85～264V |
75W |
5V 15A |
|
PBA75F-9 |
1Φ AC85～264V |
75.6W |
9V 8.4A |
|
PBA75F-12 |
1Φ AC85～264V |
75.6W |
12V 6.3A |
|
PBA75F-15 |
1Φ AC85～264V |
75W |
15V 5A |
|
PBA75F-24 |
1Φ AC85～264V |
76.8W |
24V 3.2A |
|
PBA75F-36 |
1Φ AC85～264V |
75.6W |
36V 2.1A |
|
PBA75F-48 |
1Φ AC85～264V |
76.8W |
48V 1.6A |
|
PBA100F-3R3 |
1Φ AC85～264V |
66W |
3.3V 20A |
|
PBA100F-5 |
1Φ AC85～264V |
100W |
5V 20A |
|
PBA100F-9 |
1Φ AC85～264V |
94.5W |
9V 10.5A |
|
PBA100F-12 |
1Φ AC85～264V |
102W |
12V 8.5A |
|
PBA100F-15 |
1Φ AC85～264V |
105W |
15V 7A |
|
PBA100F-24 |
1Φ AC85～264V |
108W |
24V 4.5A |
|
PBA100F-36 |
1Φ AC85～264V |
100.8W |
36V 2.8A |
|
PBA100F-48 |
1Φ AC85～264V |
100.8W |
48V 2.1A |
|
PBA150F-3R3 |
1Φ AC85～264V |
99W |
3.3V 30A |
|
PBA150F-5 |
1Φ AC85～264V |
150W |
5V 30A |
|
PBA150F-9 |
1Φ AC85～264V |
150.3W |
9V 16.7A |
|
PBA150F-12 |
1Φ AC85～264V |
156W |
12V 13A |
|
PBA150F-15 |
1Φ AC85～264V |
150W |
15V 10A |
|
PBA150F-24 |
1Φ AC85～264V |
156W |
24V 6.5A |
|
PBA150F-36 |
1Φ AC85～264V |
154.8W |
36V 4.3A |
|
PBA150F-48 |
1Φ AC85～264V |
158.4W |
48V 3.3A |
|
PBA300F-3R3 |
1Φ AC85～264V |
198W |
3.3V 60A |
|
PBA300F-5 |
1Φ AC85～264V |
300W |
5V 60A |
|
PBA300F-7R5 |
1Φ AC85～264V |
300W |
7.5V 40A |
|
PBA300F-12 |
1Φ AC85～264V |
324W |
12V 27A |
|
PBA300F-15 |
1Φ AC85～264V |
330W |
15V 22A |
|
PBA300F-24 |
1Φ AC85～264V |
336W |
24V 14A ACIN 100V |
|
24V 14 (16.5) A ACIN 200V |
|||
|
PBA300F-36 |
1Φ AC85～264V |
324W |
36V 9A |
|
PBA300F-48 |
1Φ AC85～264V |
336W |
48V 7A |
|
PBA600F-3R3 |
1Φ AC85～264V |
396W |
3.3V 120A |
|
PBA600F-5 |
1Φ AC85～264V |
600W |
5V 120A |
|
PBA600F-7R5 |
1Φ AC85～264V |
600W |
7.5V 80A |
|
PBA600F-12 |
1Φ AC85～264V |
636W |
12V 53A |
|
PBA600F-15 |
1Φ AC85～264V |
645W |
15V 43A |
|
PBA600F-24 |
1Φ AC85～264V |
648W |
24V 27A ACIN 100V |
|
24V 27 (31) A ACIN 200V |
|||
|
PBA600F-36 |
1Φ AC85～264V |
648W |
36V 18A |
|
PBA600F-48 |
1Φ AC85～264V |
624W |
48V 13A |
|
PBA1000F-3R3 |
1Φ AC85～264V |
660W |
3.3V 200A |
|
PBA1000F-5 |
1Φ AC85～264V |
1000W |
5V 200A |
|
PBA1000F-7R5 |
1Φ AC85～264V |
1005W |
7.5V 134A |
|
PBA1000F-12 |
1Φ AC85～264V |
1056W |
12V 88A |
|
PBA1000F-15 |
1Φ AC85～264V |
1050W |
15V 70A |
|
PBA1000F-24 |
1Φ AC85～264V |
1056W |
24V 44A ACIN 100V |
|
1Φ AC85～264V |
24V 44 (51) A ACIN 200V |
||
|
PBA1000F-36 |
1Φ AC85～264V |
1044W |
36V 29A |
|
PBA1000F-48 |
1Φ AC85～264V |
1056W |
48V 22A |
|
PBA1500F-3R3 |
1Φ AC85～264V |
990W |
3.3V 300A |
|
PBA1500F-5 |
1Φ AC85～264V |
1500W |
5V 300A |
|
PBA1500F-7R5 |
1Φ AC85～264V |
1500W |
7.5V 200A |
|
PBA1500F-12 |
1Φ AC85～264V |
1500W |
12V 125A |
|
PBA1500F-15 |
1Φ AC85～264V |
1500W |
15V 100A |
|
PBA1500F-24 |
1Φ AC85～264V |
1680W |
24V 65A ACIN 100V |
|
24V 70 (105) A ACIN 200V |
|||
|
PBA1500F-36 |
1Φ AC85～264V |
1692W |
36V 42A ACIN 100V |
|
36V 47A (70) A ACIN 200V |
|||
|
PBA1500F-48 |
1Φ AC85～264V |
1680W |
48V 32A |
|
PBA1500T-5 |
3Φ AC170～264V |
1500W |
5V 300A |
|
PBA1500T-12 |
3Φ AC170～264V |
1500W |
12V 125A |
|
PBA1500T-24 |
3Φ AC170～264V |
1680W |
24V 70A (105) A |
|
PBA1500T-48 |
3Φ AC170～264V |
1680W |
48V 35A |
