• High Efficency
• Small and compact PCB construction
• Low Noise
• Harmonic attenuator (Complies with IEC61000-3-2)
• Extensive optional parts such as dedicated harness are available
• Wide operating temperature
• Complies with SEMI F47
LH(1) A(2) 30(3) F(4) - □(5) - □(6)
(1) Series name
(2) Single output
(3) Output wattage
(4) Universal input
(5) Output voltage
(6) Optional
C: with Coating
G: Low leakage current
J4: EP (Tyco) connector type
S: with Chassis
SN: with Chassis & cover
Y: with Potentiometer
Please refer to Instruction manual 6.
| 型號 | 輸入電壓 | 輸出瓦數 | 輸出電壓／電流 |
| LHA10F-3R3-Y | 1Φ AC85～264V | 6.6W | 3.3V 2A |
| LHA10F-5 | 1Φ AC85～264V | 10.0W | 5V 2A |
| LHA10F-12 | 1Φ AC85～264V | 10.8W | 12V 0.9A |
| LHA10F-15 | 1Φ AC85～264V | 10.5W | 15V 0.7A |
| LHA10F-24 | 1Φ AC85～264V | 12.0W | 24V 0.5A |
| LHA15F-3R3-Y | 1Φ AC85～264V | 9.9W | 3.3V 3A |
| LHA15F-5 | 1Φ AC85～264V | 15.0W | 5V 3A |
| LHA15F-12 | 1Φ AC85～264V | 15.6W | 12V 1.3A |
| LHA15F-15 | 1Φ AC85～264V | 15.0W | 15V 1A |
| LHA15F-24 | 1Φ AC85～264V | 16.8W | 24V 0.7A |
| LHA30F-3R3-Y | 1Φ AC85～264V | 19.8W | 3.3V 6A |
| LHA30F-5 | 1Φ AC85～264V | 30.0W | 5V 6A |
| LHA30F-12 | 1Φ AC85～264V | 30.0W | 12V 2.5A |
| LHA30F-15 | 1Φ AC85～264V | 30.0W | 15V 2A |
| LHA30F-24 | 1Φ AC85～264V | 31.2W | 24V 1.3A |
| LHA50F-3R3-Y | 1Φ AC85～264V | 26.4W | 3.3V 8A |
| LHA50F-5 | 1Φ AC85～264V | 40W | 5V 8A |
| LHA50F-12 | 1Φ AC85～264V | 51.6W | 12V 4.3A |
| LHA50F-15 | 1Φ AC85～264V | 52.5W | 15V 3.5A |
| LHA50F-24 | 1Φ AC85～264V | 50.4W | 24V 2.1A |
| LHA50F-36 | 1Φ AC85～264V | 50.4W | 36V 1.4A |
| LHA50F-48 | 1Φ AC85～264V | 52.8W | 48V 1.1A |
| LHA75F-3R3-Y | 1Φ AC85～264V | 39.6W | 3.3V 12A |
| LHA75F-5 | 1Φ AC85～264V | 60W | 5V 12A |
| LHA75F-12 | 1Φ AC85～264V | 75.6W | 12V 6.3A |
| LHA75F-15 | 1Φ AC85～264V | 75W | 15V 5A |
| LHA75F-24 | 1Φ AC85～264V | 76.8W | 24V 3.2A |
| LHA75F-36 | 1Φ AC85～264V | 75.6W | 36V 2.1A |
| LHA75F-48 | 1Φ AC85～264V | 76.8W | 48V 1.6A |
| LHA100F-5 | 1Φ AC85～264V | 75W | 5V 15A |
| LHA100F-12 | 1Φ AC85～264V | 102W | 12V 8.5A |
| LHA100F-15 | 1Φ AC85～264V | 100.5W | 15V 6.7A |
| LHA100F-24 | 1Φ AC85～264V | 103.2W | 24V 4.3A |
| LHA100F-36 | 1Φ AC85～264V | 100.8W | 36V 2.8A |
| LHA100F-48 | 1Φ AC85～264V | 100.8W | 48V 2.1A |
| LHA150F-12 | 1Φ AC85～264V | 150W | 12V 12.5A |
| LHA150F-24 | 1Φ AC85～264V | 151.2W | 24V 6.3A |
| LHA150F-36 | 1Φ AC85～264V | 151.2W | 36V 4.2A |
| LHA150F-48 | 1Φ AC85～264V | 153.6W | 48V 3.2A |
| LHA300F-12-Y | 1Φ AC85～264V | 300W | 12V 25A |
| LHA300F-24-Y | 1Φ AC85～264V | 300W | 24V 12.5A |
| LHA300F-48-Y | 1Φ AC85～264V | 302.4W | 48V 6.3A |
如需產品圖檔，請洽廣億科技服務人員，謝謝！
