• Low profile (41mm, 1.61inch = meet 1U height)
• For medical electric equipment
(ANSI/AAMI ES60601-1, EN60601-1 3rd, IEC60601-1-2 4th Ed.)
• Medical Isolation Grade 2MOPP
• With AUX output 12V 0.1A (Voltage variable range 5 - 12V)
• Constant current function
• Output voltage can be adjusted to near 0V
• With various alarms
• Parallel Operation / N+1 Parallel Redundancy Operation possible
• Monitoring function and various setting values can be changed by communication
•Complies with SEMI F-47(Io:100%max at ACIN 200V, 70%max at ACIN 100V)

PC⁽¹⁾　A⁽²⁾　300⁽³⁾　F⁽⁴⁾　-　5⁽⁵⁾　-　□⁽⁶⁾　

(1) Series name
(2) Single output
(3) Output wattage
(4) Universal input
(5) Output voltage
(6) Optional
  C: with Coating
  G: Low leakage current
  T: Terminal Block Style
  I: with PMBus interface
  F2: Reverse air exhaust type
  P3: Master-slave Operation
  W1: Alarm function
For option details, refer to instruction manual 6.1.
