• For medical electric equipment
• Internal dual fuses
• Harmonic attenuator (Complies with IEC61000-3-2)
• Universal input (AC85 - 264V)
• Efficiency increased with synchronous rectification technology (PMA60F, PMA100F)
• Variety of option
PM(1) A(2) 15(3) F(4) - □(5) - □(6)
(1) Series name
(2) Single output
(3) Output wattage
(4) Universal input
(5) Output voltage
(6) Optional
T: Vertical terminal block
T1: Horizontal terminal block
N: with Cover
J1: VH (J.S.T) connector type
Specification is changed at option, refer to Instruction Manual.
|
型號 |
輸入電壓 |
輸出瓦數 |
輸出電壓／電流 |
|
PMA15F-3R3 |
1Φ AC85～264V |
9.9W |
3.3V 3A |
|
PMA15F-5 |
1Φ AC85～264V |
15W |
5V 3A |
|
PMA15F-12 |
1Φ AC85～264V |
15.6W |
12V 1.3A |
|
PMA15F-15 |
1Φ AC85～264V |
15W |
15V 1A |
|
PMA15F-24 |
1Φ AC85～264V |
16.8W |
24V 0.7A |
|
PMA30F-3R3 |
1Φ AC85～264V |
19.8W |
3.3V 6A |
|
PMA30F-5 |
1Φ AC85～264V |
30W |
5V 6A |
|
PMA30F-12 |
1Φ AC85～264V |
30W |
12V 2.5A |
|
PMA30F-15 |
1Φ AC85～264V |
30W |
15V 2A |
|
PMA30F-24 |
1Φ AC85～264V |
31.2W |
24V 1.3A |
|
PMA60F-3R3 |
1Φ AC85～264V |
39.6W |
3.3V 12A |
|
PMA60F-5 |
1Φ AC85～264V |
60W |
5V 12A |
|
PMA60F-12 |
1Φ AC85～264V |
60W |
12V 5A |
|
PMA60F-15 |
1Φ AC85～264V |
60W |
15V 4A |
|
PMA60F-24 |
1Φ AC85～264V |
60W |
24V 2.5A |
|
PMA100F-3R3 |
1Φ AC85～264V |
66W |
3.3V 20A |
|
PMA100F-5 |
1Φ AC85～264V |
100W |
5V 20A |
|
PMA100F-12 |
1Φ AC85～264V |
102W |
12V 8.5A |
|
PMA100F-24 |
1Φ AC85～264V |
108W |
24V 4.5A |
|
PMA100F-48 |
1Φ AC85～264V |
100.8W |
48V 2.1A |
如需產品圖檔，請洽廣億科技服務人員，謝謝！
