• Super small-size & light weight
• Harmonic attenuator (Complies with IEC61000-3-2) : except PBA1500T
• Universal input (AC85 - 264V) : PBA1500T AC170-264V 3Φ
• Efficiency increased with synchronous rectification technology (PBA50F - 150F)
• Variety of option (PBA10F - 150F, PBW15F - 50F)
• Parallel operation and Parallel redundancy operation (PBA300F - 1500F, PBA1500T)
• Fan alarm, Remote ON/OFF and other functions (PBA300F - 1500F, PBA1500T)
PB(1) W(2) 15(3) F(4) - □(5) - □(6)
(1) Series name
(2) Dual output
(3) Output wattage
(4) Universal input
(5) Output voltage
(6) Optional
C: with Coating
G: Low leakage current
E: Low leakage current and EMI class A
T: Vertical terminal block
J: Connector type
N: with Cover
N1: with DIN rail
V: Output voltage setting potentiometer externally
|
型號 |
輸入電壓 |
輸出瓦數 |
輸出電壓／電流 |
|
PBW15F-12 |
1Φ AC85～264V |
16.8W |
±12V (+24V) |
|
Rated Current1: 0.7A |
|||
|
Rated Current2: 1.4A * (CURRENT2) |
|||
|
PBW15F-15 |
1Φ AC85～264V |
15.0W |
±15V (+30V) |
|
Rated Current1: 0.5A |
|||
|
Rated Current2: 1.0A * |
|||
|
PBW30F-5 |
1Φ AC85～264V |
15W |
±5V (+10V) |
|
Rated Current1: 1.5A |
|||
|
Rated Current2: 2.0A * |
|||
|
PBW30F-12 |
1Φ AC85～264V |
31.2W |
±12V (+24V) |
|
Rated Current1: 1.3A |
|||
|
Rated Current2: 1.7A * |
|||
|
PBW30F-15 |
1Φ AC85～264V |
30.0W |
±15V (+30V) |
|
Rated Current1: 1.0A |
|||
|
Rated Current2: 1.4A * |
|||
|
PBW50F-5 |
1Φ AC85～264V |
30W |
±5V (+10V) |
|
Rated Current1: 3.0A |
|||
|
Rated Current2: 4.0A * |
|||
|
PBW50F-12 |
1Φ AC85～264V |
50.4W |
±12V (+24V) |
|
Rated Current1: 2.1A |
|||
|
Rated Current2: 2.7A * |
|||
|
PBW50F-15 |
1Φ AC85～264V |
51W |
±15V (+30V) |
|
Rated Current1: 1.7A |
|||
|
Rated Current2: 2.4A * |
如需產品圖檔，請洽廣億科技服務人員，謝謝！
