• Equipped with improved power factor, open phase detection and overheating detection circuits
• Can optionally feature sequence unit for DC-DC converter ON/OFF control
• Conducted noise EN55022 class B (When combined with recommended filter + DBS series unit)
• Small and light weight
STA(1) 5000(2) T(3) - □(4)
(1) Series name
(2) Output wattage
(3) Triple input phase
(4) Optional
R: with Sequence unit
|
型號 |
輸入電壓 |
輸出瓦數 |
輸出電壓／電流 |
|
STA5000T |
3Φ AC170～264V |
5000W |
DC230 - 370V |
如需產品圖檔，請洽廣億科技服務人員，謝謝！
