• Rugged PCB type (CEM)
• Harmonic attenuator (Complies with IEC61000-3-2)
• Universal input voltage (AC85 - 264V)
• Remote ON/OFF (Option)
LEB(1) 100(2) F(3) - 05(4) 24(5) - □(6)
(1) Series name
(2) Output wattage
(3) Universal input
(4) V1 output voltage
(5) V2 output voltage
(6) Optional
G: Low leakage current
R: with Remote ON/OFF
S: with Chassis
SN: with Chassis & cover
T: Vertical terminal block
Y: with Potentiometer
Z: with ZT
|
型號 |
輸入電壓 |
輸出瓦數 |
輸出電壓／電流 |
|
LEB100F-0324 |
1Φ AC85～264V |
100W (Peak: 172W) |
V1: +3.3V 5A |
|
V2: +24V 4A (Peak: 7A) |
|||
|
LEB100F-0512 |
1Φ AC85～264V |
85W (Peak: 145W) |
V1: +5V 5A |
|
V2: +12V 5A (Peak: 10A) |
|||
|
LEB100F-0524 |
1Φ AC85～264V |
100W (Peak: 172W) |
V1: +5V 5A |
|
V2: +24V 4A (Peak: 7A) |
|||
|
LEB100F-0530 |
1Φ AC85～264V |
100W (Peak: 172W) |
V1: +5V 5A |
|
V2: +30V 3.2A (Peak: 5.6A) |
|||
|
LEB100F-0536 |
1Φ AC85～264V |
100W (Peak: 172W) |
V1: +5V 5A |
|
V2: +36V 2.7A (Peak: 4.7A) |
|||
|
LEB150F-0324 |
1Φ AC85～264V |
150W (Peak: 246W) |
V1: +3.3V 5A |
|
V2: +24V 6A (Peak: 10A) |
|||
|
LEB150F-0512 |
1Φ AC85～264V |
115W (Peak: 193W) |
V1: +5V 5A |
|
V2: +12V 7.5A (Peak: 14A) |
|||
|
LEB150F-0524 |
1Φ AC85～264V |
150W (Peak: 246W) |
V1: +5V 5A |
|
V2: +24V 6A (Peak: 10A) |
|||
|
LEB150F-0530 |
1Φ AC85～264V |
150W (Peak: 246W) |
V1: +5V 5A |
|
V2: +30V 4.8A (Peak: 8A) |
|||
|
LEB150F-0536 |
1Φ AC85～264V |
150W (Peak: 246W) |
V1: +5V 5A |
|
V2: +36V 4A (Peak: 6.7A) |
|||
|
LEB225F-0324 |
1Φ AC85～264V |
225W (Peak: 345W) |
V1: +3.3V 5A |
|
V2: +24V 9A (Peak: 14A) |
|||
|
LEB225F-0512 |
1Φ AC85～264V |
145W (Peak: 265W) |
V1: +5V 5A |
|
V2: +12V 10A (Peak: 20A) |
|||
|
LEB225F-0524 |
1Φ AC85～264V |
225W (Peak: 345W) |
V1: +5V 5A |
|
V2: +24V 9A (Peak: 14A) |
|||
|
LEB225F-0530 |
1Φ AC85～264V |
225W (Peak: 345W) |
V1: +5V 5A |
|
V2: +30V 7.2A (Peak: 11A) |
|||
|
LEB225F-0536 |
1Φ AC85～264V |
225W (Peak: 345W) |
V1: +5V 5A |
|
V2: +36V 6A (Peak: 9.3A) |
如需產品圖檔，請洽廣億科技服務人員，謝謝！
