• Industry Standard
SIP6 (MGXS1R5) , SIP8 (MGXS6)
• Ultra wide input range (MGXS) DC6 - 60V
• I/O isolation voltage DC1,500V (1 minute)
• Built-in overcurrent protection circuits (recovers automatically)
• Built-in remote ON/OFF (MGXS6)
• High reliability : not built-in aluminum and tantalum electrolytic capacitor
MGX(1) S(2) 1R5(3) 24(4) 05(5) - □(6)
(1) Series name
(2) Single output
(3) Output wattage
(4) Input voltage
(5) Output voltage
(6) Optional
Y2 : Output voltage adjustable (+10%, -5%)
|
型號 |
輸入電壓 |
輸出瓦數 |
輸出電壓／電流 |
|
MGXS1R5243R3 |
DC6-60V |
1.32W |
3.3V 0.4A |
|
MGXS1R52405 |
DC6-60V |
1.5W |
5V 0.3A |
|
MGXS1R52412 |
DC6-60V |
1.56W |
12V 0.13A |
|
MGXS1R52415 |
DC6-60V |
1.5W |
15V 0.1A |
|
MGXS6243R3 |
DC6-60V |
5.28W |
3.3V 1.6A |
|
MGXS62405 |
DC6-60V |
6W |
5V 1.2A |
|
MGXS62412 |
DC6-60V |
6W |
12V 0.5A |
|
MGXS62415 |
DC6-60V |
6W |
15V 0.4A |
如需產品圖檔，請洽廣億科技服務人員，謝謝！
