• SMD mounting type and through-hole mounting type
• High efficiency (synchronous rectifier circuit)
• Parallel operation is possible
• Built-in overcurrent, overvoltage and lowvoltage circuits
• Built-in remote ON/OFF, alarm
• High reliability: not built-in aluminum and tantalum electrolytic capacitor
SFC(1) S(2) 15(3) 24(4) 3R3(5) C(6)
(1) Series name
(2) Single output
(3) Output wattage
(4) Input voltage
24: DC18 - 36V
48: DC36 - 76V
(5) Output voltage
(6) Mounting type
B: SMD
C: DIP
|
型號 |
輸入電壓 |
輸出瓦數 |
輸出電壓／電流 |
|
SFCS15243R3 |
DC18-36V/DC36-76V |
14.85W |
3.3V 4.5A |
|
SFCS152405 |
DC18-36V/DC36-76V |
15.0W |
5V 3A |
|
SFCS152412 |
DC18-36V/DC36-76V |
15.0W |
12V 1.25A |
|
SFCS152415 |
DC18-36V/DC36-76V |
15.0W |
15V 1A |
|
SFCS15483R3 |
DC18-36V/DC36-76V |
14.85W |
3.3V 4.5A |
|
SFCS154805 |
DC18-36V/DC36-76V |
15.0W |
5V 3A |
|
SFCS154812 |
DC18-36V/DC36-76V |
15.0W |
12V 1.25A |
|
SFCS154815 |
DC18-36V/DC36-76V |
15.0W |
15V 1A |
|
SFCS30243R3 |
DC18-36V/DC36-76V |
29.7W |
3.3V 9A |
|
SFCS302405 |
DC18-36V/DC36-76V |
30.0W |
5V 6A |
|
SFCS302412 |
DC18-36V/DC36-76V |
30.0W |
12V 2.5A |
|
SFCS302415 |
DC18-36V/DC36-76V |
30.0W |
15V 2A |
|
SFCS30483R3 |
DC18-36V/DC36-76V |
29.7W |
3.3V 9A |
|
SFCS304805 |
DC18-36V/DC36-76V |
30.0W |
5V 6A |
|
SFCS304812 |
DC18-36V/DC36-76V |
30.0W |
12V 2.5A |
|
SFCS304815 |
DC18-36V/DC36-76V |
30.0W |
15V 2A |
