• Thin profile
• Isolated between input-output
• Built-in overcurrent protection circuit
• UL recognized, TÜV approved, CSA certified
ZT(1) S(2) 3(3) 12(4) 05(5)
(1) Series name
(2) Single output
(3) Output wattage
(4) Input voltage
(5) Output voltage
|
型號 |
輸入電壓 |
輸出瓦數 |
輸出電壓／電流 |
|
ZTS1R50505 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-72V |
1.50W |
5V 0.30A |
|
ZTS1R50512 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-72V |
1.56W |
12V 0.13A |
|
ZTS1R50515 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-72V |
1.50W |
15V 0.10A |
|
ZTS1R51205 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-72V |
1.50W |
5V 0.30A |
|
ZTS1R51212 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-72V |
1.56W |
12V 0.13A |
|
ZTS1R51215 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-72V |
1.50W |
15V 0.10A |
|
ZTS1R52405 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-72V |
1.50W |
5V 0.30A |
|
ZTS1R52412 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-72V |
1.56W |
12V 0.13A |
|
ZTS1R52415 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-72V |
1.50W |
15V 0.10A |
|
ZTS1R54805 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-72V |
1.50W |
5V 0.30A |
|
ZTS1R54812 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-72V |
1.56W |
12V 0.13A |
|
ZTS1R54815 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-72V |
1.50W |
15V 0.10A |
|
ZTS30505 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-72V |
3W |
5V 0.60A |
|
ZTS30512 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-72V |
3W |
12V 0.25A |
|
ZTS30515 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-72V |
3W |
15V 0.20A |
|
ZTS31205 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-72V |
3W |
5V 0.60A |
|
ZTS31212 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-72V |
3W |
12V 0.25A |
|
ZTS31215 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-72V |
3W |
15V 0.20A |
|
ZTS32405 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-72V |
3W |
5V 0.60A |
|
ZTS32412 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-72V |
3W |
12V 0.25A |
|
ZTS32415 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-72V |
3W |
15V 0.20A |
|
ZTS34805 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-72V |
3W |
5V 0.60A |
|
ZTS34812 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-72V |
3W |
12V 0.25A |
|
ZTS34815 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-72V |
3W |
15V 0.20A |
如需產品圖檔，請洽廣億科技服務人員，謝謝！
