• Industry Standard
SIP6 (MGW1R5/MGW3) , SIP8 (MGW6/MGW10)
1"X1" (MGW15) , 1"X2" (MGW30)
• 6 sided shield (MGW15/MGW30)
• I/O isolation voltage DC1,500V (1 minute)
• Built-in overcurrent protection circuits (recovers automatically)
• Built-in overvoltage protection circuits (MGW30)
• Built-in remote ON/OFF (MGW6/MGW10/MGW15/MGW30)
• High reliability : not built-in aluminum and tantalum electrolytic capacitor
MG(1) W(2) 3(3) 24(4) 12(5) - □(6)
(1) Series name
(2) Dual output
(3) Output wattage
(4) Input voltage
(5) Output voltage
(6) Optional
|
型號 |
輸入電壓 |
輸出瓦數 |
輸出電壓／電流 |
|
MGW1R50512 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
1.56W |
±12V (+24V) 0.065A |
|
MGW1R50515 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
1.5W |
±15V (+30V) 0.05A |
|
MGW1R51212 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
1.56W |
±12V (+24V) 0.065A |
|
MGW1R51215 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
1.5W |
±15V (+30V) 0.05A |
|
MGW1R52412 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
1.56W |
±12V (+24V) 0.065A |
|
MGW1R52415 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
1.5W |
±15V (+30V) 0.05A |
|
MGW1R54812 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
1.56W |
±12V (+24V) 0.065A |
|
MGW1R54815 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
1.5W |
±15V (+30V) 0.05A |
|
MGW30512 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
3.12W |
±12V (+24V) 0.13A |
|
MGW30515 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
3W |
±15V (+30V) 0.1A |
|
MGW31212 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
3.12W |
±12V (+24V) 0.13A |
|
MGW31215 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
3W |
±15V (+30V) 0.1A |
|
MGW32412 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
3.12W |
±12V (+24V) 0.13A |
|
MGW32415 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
3W |
±15V (+30V) 0.1A |
|
MGW34812 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
3.12W |
±12V (+24V) 0.13A |
|
MGW34815 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
3W |
±15V (+30V) 0.1A |
|
MGW60512 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
6W |
±12V (+24V) 0.25A |
|
MGW60515 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
6W |
±15V (+30V) 0.2A |
|
MGW61212 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
6W |
±12V (+24V) 0.25A |
|
MGW61215 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
6W |
±15V (+30V) 0.2A |
|
MGW62412 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
6W |
±12V (+24V) 0.25A |
|
MGW62415 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
6W |
±15V (+30V) 0.2A |
|
MGW64812 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
6W |
±12V (+24V) 0.25A |
|
MGW64815 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
6W |
±15V (+30V) 0.2A |
|
MGW100512 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
10.08W |
±12V (+24V) 0.42A |
|
MGW100515 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
10.20W |
±15V (+30V) 0.34A |
|
MGW101212 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
10.08W |
±12V (+24V) 0.42A |
|
MGW101215 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
10.20W |
±15V (+30V) 0.34A |
|
MGW102412 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
10.08W |
±12V (+24V) 0.42A |
|
MGW102415 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
10.20W |
±15V (+30V) 0.34A |
|
MGW104812 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
10.08W |
±12V (+24V) 0.42A |
|
MGW104815 |
DC4.5-9V/DC9-18V/DC18-36V/DC36-76V |
10.20W |
±15V (+30V) 0.34A |
|
MGW151205 |
DC9-18V/DC18-36V/DC36-76V |
15W |
±5V (+10V) 1.5A |
|
MGW151212 |
DC9-18V/DC18-36V/DC36-76V |
15.6W |
±12V (+24V) 0.65A |
|
MGW151215 |
DC9-18V/DC18-36V/DC36-76V |
15W |
±15V (+30V) 0.5A |
|
MGW152405 |
DC9-18V/DC18-36V/DC36-76V |
15W |
±5V (+10V) 1.5A |
|
MGW152412 |
DC9-18V/DC18-36V/DC36-76V |
15.6W |
±12V (+24V) 0.65A |
|
MGW152415 |
DC9-18V/DC18-36V/DC36-76V |
15W |
±15V (+30V) 0.5A |
|
MGW154805 |
DC9-18V/DC18-36V/DC36-76V |
15W |
±5V (+10V) 1.5A |
|
MGW154812 |
DC9-18V/DC18-36V/DC36-76V |
15.6W |
±12V (+24V) 0.65A |
|
MGW154815 |
DC9-18V/DC18-36V/DC36-76V |
15W |
±15V (+30V) 0.5A |
|
MGW301205 |
DC9-18V/DC18-36V/DC36-76V |
25W |
±5V (+10V) 2.5A |
|
MGW301212 |
DC9-18V/DC18-36V/DC36-76V |
30W |
±12V (+24V) 1.25A |
|
MGW301215 |
DC9-18V/DC18-36V/DC36-76V |
30W |
±15V (+30V) 1A |
|
MGW302405 |
DC9-18V/DC18-36V/DC36-76V |
25W |
±5V (+10V) 2.5A |
|
MGW302412 |
DC9-18V/DC18-36V/DC36-76V |
30W |
±12V (+24V) 1.25A |
|
MGW302415 |
DC9-18V/DC18-36V/DC36-76V |
30W |
±15V (+30V) 1A |
|
MGW304805 |
DC9-18V/DC18-36V/DC36-76V |
25W |
±5V (+10V) 2.5A |
|
MGW304812 |
DC9-18V/DC18-36V/DC36-76V |
30W |
±12V (+24V) 1.25A |
|
MGW304815 |
DC9-18V/DC18-36V/DC36-76V |
30W |
±15V (+30V) 1A |
