• Industry Standard
SIP6 (MGXW1R5) , SIP8 (MGXW6)
• Ultra wide input range (MGXW) DC6 - 60V
• I/O isolation voltage DC1,500V (1 minute)
• Built-in overcurrent protection circuits (recovers automatically)
• Built-in remote ON/OFF (MGXW6)
• High reliability : not built-in aluminum and tantalum electrolytic capacitor
MGX(1) W(2) 6(3) 24(4) 12(5) - □(6)
(1) Series name
(2) Dual output
(3) Output wattage
(4) Input voltage
(5) Output voltage
(6) Optional
Y2 : Output voltage adjustable (+10%, -5%)
|
型號 |
輸入電壓 |
輸出瓦數 |
輸出電壓／電流 |
|
MGXW1R52412 |
DC6-60V |
1.56W |
±12V (+24V) 0.065A |
|
MGXW1R52415 |
DC6-60V |
1.5W |
±15V (+30V) 0.05A |
|
MGXW62412 |
DC6-60V |
6W |
±12V (+24V) 0.25A |
|
MGXW62415 |
DC6-60V |
6W |
±15V (+30V) 0.2A |
如需產品圖檔，請洽廣億科技服務人員，謝謝！
