• Isolated unit type DC-DC converter
• Wide input voltage DC9-36V/DC18-76V
Various lineups
• Available connector interface (option)
• Available case cover (option)
• Available DIN rail attachment (option)
• Built in Overcurrent protection (recovery automatically)
• Built in Overvoltage protection (for STMG30)
• Built in Remote ON/OFF
• Built in Output voltage adjustment (for single output, ±10%)

STMGF⁽¹⁾  W⁽²⁾  15⁽³⁾  24⁽⁴⁾  05⁽⁵⁾  -  □⁽⁶⁾

(1) Series name
(2) Dual output
(3) Output wattage
(4) Input voltage
(5) Output voltage
(6) Optional
  G: Capacitor between Input and Output is removed.
  R: with Remote ON/OFF
    (Positive logic control)
  J: Input/Output Connector
  JN1: Connector with case cover
  N2: With DIN rail installation type
  JN3: Connector with cover (plastic) and DIN rail installation type

* When the option is set specifications may vary.
