• Small size and high efficiency non-isolated DC-DC converter.
• Wide input voltage 4.5V to 14.0V.
• Fast transient respoce by Robust control.
• Built-in remote ON/OFF, Power good, Start-up sequence.
• Built-in overcurrent and thermal protection (auto recovery type) functions.
• PMBus interface for programming, margining, and telemetry.
BRD(1) S(2) 60(3) S(4)- □(5)
(1) Series name
(2) Single output
(3) Output current
40: 40A
60: 60A
100: 100A
120: 120A
150: 150A
(4) Type
Blank: Standard type
S: Small type (only 60A)
(5) Optional
R: Positive logic remote on/off
D: With switching frequency synchronization function (BRDS120 and BRDS150)
L : High thermal dissipation (BRDS120 and BRDS150)
|
型號 |
輸入電壓 |
輸出瓦數 |
輸出電壓／電流 |
|
BRDS40 |
DC4.5-14.0V |
- |
1.2V 40.0A |
|
BRDS60 |
DC4.5-14.0V |
- |
1.2V 60.0A |
|
BRDS60S |
DC4.5-14.0V |
- |
1.2V 60.0A |
|
BRDS100 |
DC4.5-14.0V |
- |
1.2V 100.0A |
|
BRDS120 |
DC4.5-14.0V |
- |
1.2V 120.0A |
|
BRDS150 |
DC4.5-14.0V |
- |
1.2V 150.0A |
如需產品圖檔，請洽廣億科技服務人員，謝謝！
