lmprove differential mode attenuation (Rated voltage 250V)
Selectable leakage current value
TAC(1) - 04(2) - 683(3) - □(4)
(1) Model Name
(2) Rated Current
(3) Line to ground capacitor code
Refer to Product Line-up.
(4) Options
D:DIN rail installation type
* The dimensions change when the option is set. Refer to External view.
|
型號 |
漏電流 |
コンデンサ容量（公称値） |
額定電壓 |
額定電流 |
|
TAC-04-103 |
0.5mA / 1.0mA max |
10,000pF |
三相三線式 500V 50/60Hz |
4A |
|
TAC-04-223 |
1.0mA / 2.0mA max |
22,000pF |
三相三線式 500V 50/60Hz |
4A |
|
TAC-04-683 |
2.5mA / 5.0mA max |
68,000pF |
三相三線式 500V 50/60Hz |
4A |
|
TAC-06-103 |
0.5mA / 1.0mA max |
10,000pF |
三相三線式 500V 50/60Hz |
6A |
|
TAC-06-223 |
1.0mA / 2.0mA max |
22,000pF |
三相三線式 500V 50/60Hz |
6A |
|
TAC-06-683 |
2.5mA / 5.0mA max |
68,000pF |
三相三線式 500V 50/60Hz |
6A |
|
TAC-10-103 |
0.5mA / 1.0mA max |
10,000pF |
三相三線式 500V 50/60Hz |
10A |
|
TAC-10-223 |
1.0mA / 2.0mA max |
22,000pF |
三相三線式 500V 50/60Hz |
10A |
|
TAC-10-683 |
2.5mA / 5.0mA max |
68,000pF |
三相三線式 500V 50/60Hz |
10A |
|
TAC-20-103 |
0.5mA / 1.0mA max |
10,000pF |
三相三線式 500V 50/60Hz |
20A |
|
TAC-20-223 |
1.0mA / 2.0mA max |
22,000pF |
三相三線式 500V 50/60Hz |
20A |
|
TAC-20-683 |
2.5mA / 5.0mA max |
68,000pF |
三相三線式 500V 50/60Hz |
20A |
|
TAC-30-103 |
0.5mA / 1.0mA max |
10,000pF |
三相三線式 500V 50/60Hz |
30A |
|
TAC-30-223 |
1.0mA / 2.0mA max |
22,000pF |
三相三線式 500V 50/60Hz |
30A |
|
TAC-30-683 |
2.5mA / 5.0mA max |
68,000pF |
三相三線式 500V 50/60Hz |
30A |
|
TAC-50-103 |
1.0mA / 2.0mA max |
10,000pF |
三相三線式 500V 50/60Hz |
50A |
|
TAC-50-223 |
2.5mA / 5.0mA max |
22,000pF |
三相三線式 500V 50/60Hz |
50A |
|
TAC-50-333 |
3.5mA / 7.0mA max |
33,000pF |
三相三線式 500V 50/60Hz |
50A |
|
TAC-60-103 |
1.0mA / 2.0mA max |
10,000pF |
三相三線式 500V 50/60Hz |
60A |
|
TAC-60-223 |
2.5mA / 5.0mA max |
22,000pF |
三相三線式 500V 50/60Hz |
60A |
|
TAC-60-333 |
3.5mA / 7.0mA max |
33,000pF |
三相三線式 500V 50/60Hz |
60A |
|
TAC-80-103 |
1.0mA / 2.0mA max |
10,000pF |
三相三線式 500V 50/60Hz |
80A |
|
TAC-80-223 |
2.5mA / 5.0mA max |
22,000pF |
三相三線式 500V 50/60Hz |
80A |
|
TAC-80-333 |
3.5mA / 7.0mA max |
33,000pF |
三相三線式 500V 50/60Hz |
80A |
|
TAC-100-103 |
1.0mA / 2.0mA max |
10,000pF |
三相三線式 500V 50/60Hz |
100A |
|
TAC-100-223 |
2.5mA / 5.0mA max |
22,000pF |
三相三線式 500V 50/60Hz |
100A |
|
TAC-100-333 |
3.5mA / 7.0mA max |
33,000pF |
三相三線式 500V 50/60Hz |
100A |
|
TAC-150-103 |
1.0mA / 2.0mA max |
10,000pF |
三相三線式 500V 50/60Hz |
150A |
|
TAC-150-223 |
2.5mA / 5.0mA max |
22,000pF |
三相三線式 500V 50/60Hz |
150A |
|
TAC-150-333 |
3.5mA / 7.0mA max |
33,000pF |
三相三線式 500V 50/60Hz |
150A |
|
TAC-200-103 |
1.0mA / 2.0mA max |
10,000pF |
三相三線式 500V 50/60Hz |
200A |
|
TAC-200-223 |
2.5mA / 5.0mA max |
22,000pF |
三相三線式 500V 50/60Hz |
200A |
|
TAC-200-333 |
3.5mA / 7.0mA max |
33,000pF |
三相三線式 500V 50/60Hz |
200A |
|
TAC-250-103 |
1.0mA / 2.0mA max |
10,000pF |
三相三線式 500V 50/60Hz |
250A |
|
TAC-250-223 |
2.5mA / 5.0mA max |
22,000pF |
三相三線式 500V 50/60Hz |
250A |
|
TAC-250-333 |
3.5mA / 7.0mA max |
33,000pF |
三相三線式 500V 50/60Hz |
250A |
|
TAC-300-103 |
1.0mA / 2.0mA max |
10,000pF |
三相三線式 500V 50/60Hz |
300A |
|
TAC-300-223 |
2.5mA / 5.0mA max |
22,000pF |
三相三線式 500V 50/60Hz |
300A |
|
TAC-300-333 |
3.5mA / 7.0mA max |
33,000pF |
三相三線式 500V 50/60Hz |
300A |
