lmprove differential mode attenuation (Rated voltage 250V)
Selectable leakage current value
TAH(1) - 60(2) - 223(3) - U(4)
(1) Model Name
(2) Rated Current
(3) Line to ground capacitor code
Refer to Product Line-up.
* When the line to ground capacitor code is different, the attenuation characteristic is
different.
(4) Options
U:Improve differential mode attenuation (Rated voltage 250V)
|
型號 |
漏電流 |
コンデンサ容量（公称値） |
額定電壓 |
額定電流 |
|
TAH-50-103-U |
1.0mA max |
10,000pF |
三相三線式 250V 50/60Hz |
50A |
|
TAH-50-223-U |
2.5mA max |
22,000pF |
三相三線式 250V 50/60Hz |
50A |
|
TAH-50-333-U |
3.5mA max |
33,000pF |
三相三線式 250V 50/60Hz |
50A |
|
TAH-60-103-U |
1.0mA max |
10,000pF |
三相三線式 250V 50/60Hz |
60A |
|
TAH-60-223-U |
2.5mA max |
22,000pF |
三相三線式 250V 50/60Hz |
60A |
|
TAH-60-333-U |
3.5mA max |
33,000pF |
三相三線式 250V 50/60Hz |
60A |
|
TAH-80-103-U |
1.0mA max |
10,000pF |
三相三線式 250V 50/60Hz |
80A |
|
TAH-80-223-U |
2.5mA max |
22,000pF |
三相三線式 250V 50/60Hz |
80A |
|
TAH-80-333-U |
3.5mA max |
33,000pF |
三相三線式 250V 50/60Hz |
80A |
|
TAH-100-103-U |
1.0mA max |
10,000pF |
三相三線式 250V 50/60Hz |
100A |
|
TAH-100-223-U |
2.5mA max |
22,000pF |
三相三線式 250V 50/60Hz |
100A |
|
TAH-100-333-U |
3.5mA max |
33,000pF |
三相三線式 250V 50/60Hz |
100A |
|
TAH-150-103-U |
1.0mA max |
10,000pF |
三相三線式 250V 50/60Hz |
150A |
|
TAH-150-223-U |
2.5mA max |
22,000pF |
三相三線式 250V 50/60Hz |
150A |
|
TAH-150-333-U |
3.5mA max |
33,000pF |
三相三線式 250V 50/60Hz |
150A |
如需產品圖檔，請洽廣億科技服務人員，謝謝！
