Space-saving type
Maximum input voltage 528VAC: 10% fluctuations in voltage 480VAC
Selectable leakage current value
Ultra high attenuation type "FTB-□□□-355-L" for EU (Wye type with neutral earth system) , motor drive system
FTB(1) - 80(2) - 663(3) - □(4)
(1) Model Name
(2) Rated Current
(3) Line to ground capacitor code
Refer to Product Line-up.
* When the line to ground capacitor code is different, the attenuation characteristic is
different.
(4) Option
H:Ultra high attenuation type
355 is not applied.
S:Hexagon socket head cap screw (Standard type is Hexagon head screw)
L:Ultra high attenuation type for EU
|
型號 |
漏電流 |
コンデンサ容量（公称値） |
額定電壓 |
額定電流 |
|
FTB-80-203 |
1.0mA / 2.0mA max |
CY1:10,000pF, CY2:10,000pF |
三相三線式 500V 50/60Hz |
80A |
|
FTB-80-663 |
2.5mA / 5.0mA max |
CY1:33,000pF, CY2:33,000pF |
三相三線式 500V 50/60Hz |
80A |
|
FTB-80-324 |
12mA / 24mA max |
CY1:220,000pF, CY2:100,000pF |
三相三線式 500V 50/60Hz |
80A |
|
FTB-80-355-L |
330mA / 515mA max |
CY1: 0.22μF, CY2: 3.3μF |
三相三線式 500V 50/60Hz |
80A |
|
FTB-100-203 |
1.0mA / 2.0mA max |
CY1:10,000pF, CY2:10,000pF |
三相三線式 500V 50/60Hz |
100A |
|
FTB-100-663 |
2.5mA / 5.0mA max |
CY1:33,000pF, CY2:33,000pF |
三相三線式 500V 50/60Hz |
100A |
|
FTB-100-324 |
12mA / 24mA max |
CY1:220,000pF, CY2:100,000pF |
三相三線式 500V 50/60Hz |
100A |
|
FTB-100-355-L |
330mA / 515mA max |
CY1: 0.22μF, CY2: 3.3μF |
三相三線式 500V 50/60Hz |
100A |
|
FTB-150-203 |
1.0mA / 2.0mA max |
CY1:10,000pF, CY2:10,000pF |
三相三線式 500V 50/60Hz |
150A |
|
FTB-150-663 |
2.5mA / 5.0mA max |
CY1:33,000pF, CY2:33,000pF |
三相三線式 500V 50/60Hz |
150A |
|
FTB-150-324 |
12mA / 24mA max |
CY1:220,000pF, CY2:100,000pF |
三相三線式 500V 50/60Hz |
150A |
|
FTB-150-355-L |
330mA / 515mA max |
CY1: 0.22μF, CY2: 3.3μF |
三相三線式 500V 50/60Hz |
150A |
如需產品圖檔，請洽廣億科技服務人員，謝謝！
