Maximum input voltage 528VAC: 10% fluctuations in voltage 480VAC
Selectable leakage current value
TBC(1) - 50(2) - 683(3)
(1) Model Name
(2) Rated Current
(3) Line to ground capacitor code
Refer to Product Line-up.
* When the line to ground capacitor code is different, the attenuation characteristic is
different.
|
型號 |
漏電流 |
コンデンサ容量（公称値） |
額定電壓 |
額定電流 |
|
TBC-50-223 |
1.0mA / 2.0mA max |
22,000pF |
三相三線式 500V 50/60Hz |
50A |
|
TBC-50-683 |
2.5mA / 5.0mA max |
68,000pF |
三相三線式 500V 50/60Hz |
50A |
|
TBC-50-104 |
3.5mA / 7.0mA max |
100,000pF |
三相三線式 500V 50/60Hz |
50A |
|
TBC-60-223 |
1.0mA / 2.0mA max |
22,000pF |
三相三線式 500V 50/60Hz |
60A |
|
TBC-60-683 |
2.5mA / 5.0mA max |
68,000pF |
三相三線式 500V 50/60Hz |
60A |
|
TBC-60-104 |
3.5mA / 7.0mA max |
100,000pF |
三相三線式 500V 50/60Hz |
60A |
|
TBC-80-223 |
1.0mA / 2.0mA max |
22,000pF |
三相三線式 500V 50/60Hz |
80A |
|
TBC-80-683 |
2.5mA / 5.0mA max |
68,000pF |
三相三線式 500V 50/60Hz |
80A |
|
TBC-80-104 |
3.5mA / 7.0mA max |
100,000pF |
三相三線式 500V 50/60Hz |
80A |
|
TBC-100-223 |
1.0mA / 2.0mA max |
22,000pF |
三相三線式 500V 50/60Hz |
100A |
|
TBC-100-683 |
2.5mA / 5.0mA max |
68,000pF |
三相三線式 500V 50/60Hz |
100A |
|
TBC-100-104 |
3.5mA / 7.0mA max |
100,000pF |
三相三線式 500V 50/60Hz |
100A |
|
TBC-150-223 |
1.0mA / 2.0mA max |
22,000pF |
三相三線式 500V 50/60Hz |
150A |
|
TBC-150-683 |
2.5mA / 5.0mA max |
68,000pF |
三相三線式 500V 50/60Hz |
150A |
|
TBC-150-104 |
3.5mA / 7.0mA max |
100,000pF |
三相三線式 500V 50/60Hz |
150A |
|
TBC-200-223 |
1.0mA / 2.0mA max |
22,000pF |
三相三線式 500V 50/60Hz |
200A |
|
TBC-200-683 |
2.5mA / 5.0mA max |
68,000pF |
三相三線式 500V 50/60Hz |
200A |
|
TBC-200-104 |
3.5mA / 7.0mA max |
100,000pF |
三相三線式 500V 50/60Hz |
200A |
|
TBC-250-223 |
1.0mA / 2.0mA max |
22,000pF |
三相三線式 500V 50/60Hz |
250A |
|
TBC-250-683 |
2.5mA / 5.0mA max |
68,000pF |
三相三線式 500V 50/60Hz |
250A |
|
TBC-250-104 |
3.5mA / 7.0mA max |
100,000pF |
三相三線式 500V 50/60Hz |
250A |
|
TBC-300-223 |
1.0mA / 2.0mA max |
22,000pF |
三相三線式 500V 50/60Hz |
300A |
|
TBC-300-683 |
2.5mA / 5.0mA max |
68,000pF |
三相三線式 500V 50/60Hz |
300A |
|
TBC-300-104 |
3.5mA / 7.0mA max |
100,000pF |
三相三線式 500V 50/60Hz |
300A |
如需產品圖檔，請洽廣億科技服務人員，謝謝！
