- μN(mgf)レベルの微小な力を高感度で検知、測定できます。
- 軽量、コンパクトなので取り扱いしやすく、研究開発や装置組み込みにも最適です。
- 形状や感度変更などのカスタマイズにも対応します。
- Capable of detecting and measuring a minute force at a μN (mgf) level with high sensitivity.
- Being lightweight and compact, this sensor is optimal for research and development and installation into equipment.
- Supports customization such as a change of the shape or the sensitivity.
Applications
微小な外力(反力)の計測や判別を必要とする様々な用途にご利用いただけます。
|
Can be used for various uses that require measurement and/or identification of a minute external force (reactive force).
- Detecting the contact in probing
- Puncture force of the needle tip
- Detecting micro contact of a brittle device
- Viscoelasticity test
- Measuring the tensile, compressive and bending forces for a test specimen
- Monitoring a micro thrust
- Measuring friction force
FS1M-1N - 微小力感應器Demo
➤ Force sensor高穩定量測的力感測器,提供專屬客製化服務
➤ 高精度荷重元,滿足各種微小力需求的Force Sensor
➤ LoadCell新選擇-微小力應力感測器
型號 |
類型 |
測量範圍 |
解析度 |
線性度 |
剛性 |
外型尺寸 |
FS1M-0.1NP |
壓力測定 |
0 ~ 100mN (≒10gf) |
20μN (≒0.002gf) |
±1% |
343 |
40×52×20 |
FS1M-0.1NT |
拉力測定 |
0 ~ 100mN (≒10gf) |
20μN (≒0.002gf) |
±1% |
343 |
40×52×20 |
FS1M-0.1NB |
壓力/拉力測定 |
±50mN (≒±5gf) |
20μN (≒0.002gf) |
±1% |
343 |
40×52×20 |
FS1M-1NP |
壓力測定 |
0 ~ 1N (≒100gf) |
0.1mN (≒0.01gf) |
±1% |
50 |
34×25×16 |
FS1M-1NT |
拉力測定 |
0 ~ 1N (≒100gf) |
0.1mN (≒0.01gf) |
±1% |
50 |
34×25×16 |
FS1M-1NB |
壓力/拉力測定 |
±0.5N (≒±50gf) |
0.1mN (≒0.01gf) |
±1% |
50 |
34×25×16 |
FS1M-5NP |
壓力測定 |
0 ~ 5N (≒500gf) |
0.5mN (≒0.05gf) |
±1% |
9.9 |
34×25×16 |
FS1M-5NT |
拉力測定 |
0 ~ 5N (≒500gf) |
0.5mN (≒0.05gf) |
±1% |
9.9 |
34×25×16 |
FS1M-5NB |
壓力/拉力測定 |
±2.5N (≒±250gf) |
0.5mN (≒0.05gf) |
±1% |
9.9 |
34×25×16 |
FSCU1-0.1N-S |
手臂形式 |
0 ~ 100mN (≒±10gf) |
50μN (≒0.005gf) |
±1% |
96.9 |
15×14×64 |
* 解析度為產品保證可觀察之最小值
